| # 1 |
1D7-13586-00 1D71358600 1D71358600 |
JOINT, CARBURETOR 1
|
||||
| # 2 |
1D7-13596-00 1D71359600 1D71359600 |
JOINT, CARBURETOR 2
|
||||
| # 3 |
5YU-13761-00 5YU1376100 5YU1376100 |
INJECTOR ASSY
|
||||
| # 4 |
5FL-14147-00 5FL1414700 5FL1414700 |
O-RING
|
||||
| # 5 |
1D7-13930-00 1D71393000 1D71393000 |
PIPE INLET ASSEMBLY
|
||||
| # 6 |
1D7-13716-00 1D71371600 1D71371600 |
COLLAR
|
||||
| # 7 |
98507-06050 9850706050 9850706050 |
SCREW, PAN
|
||||
| # 8 |
8FP-13556-00 8FP1355600 8FP1355600 |
GASKET, MANIFOLD
|
||||
| # 9 |
1D7-82509-40 1D78250940 1D78250940 |
WIRE, SUB LEAD
|
||||
| # 10 |
90464-55002 9046455002 9046455002 |
CLAMP
|
||||
| # 11 |
90445-08039 9044508039 9044508039 |
HOSE
|
||||
| # 12 |
1D7-14467-00 1D71446700 1D71446700 |
SEAL
|
||||
| # 13 |
91314-06020 9131406020 9131406020 |
BOLT, SOCKET HEAD
|
||||
| # 14 |
90450-62004 9045062004 9045062004 |
HOSE CLAMP ASSY
|
||||
| # 15 |
5C4-13750-01 5C41375001 5C41375001 |
THROTTLE BODY ASSY
|
||||
| # 16 |
3FV-14567-00 3FV1456700 3FV1456700 |
SCREW
|
||||
| # 17 |
3JD-14161-00 3JD1416100 3JD1416100 |
NUT, CABLE ADJUSTING
|
||||
| # 18 |
4KM-24453-00 4KM2445300 4KM2445300 |
SCREW
|
||||
| # 19 |
98707-04010 9870704010 9870704010 |
SCREW, FLAT
|
||||
| # 20 |
8GL-85885-00 8GL8588501008GL8588500 |
SENSITOMETRE (ENS.)
|
||||
| # 21 |
5JW-14104-00 5JW1410400 5JW1410400 |
AIR SCREW SET
|
||||
| # 22 |
895-14169-00 8951416900 8951416900 |
CAP
|
||||
| # 23 |
8A7-14139-00 8A71413900 8A71413900 |
CLIP, PIPE
|
||||
| # 24 |
1D7-13906-00 1D71390600 1D71390600 |
REGULATOR, PRESSURE
|
||||
| # 25 |
1D7-13595-00 1D71359500 1D71359500 |
JOINT
|
||||
| # 26 |
91312-05025 9131205025 9131205025 |
BOLT
|
||||
| # 27 |
1D7-13972-00 1D71397200 1D71397200 |
PIPE, FUEL 2
|
||||
| # 28 |
1D7-14493-00 1D71449300 1D71449300 |
STAY 1
|
||||
| # 29 |
1D7-13895-00 1D71389500 1D71389500 |
HOSE, AIR
|
||||
| # 30 |
95822-06012 9581206012009582206012 |
BOLT, FLANGE
|
||||
| # 31 |
90467-07093 9046707093 9046707093 |
CLIP(42X)
|
||||
| # 32 |
5PS-82380-00 5PS8238000 5PS8238000 |
SENSOR, PRESSURE
|
||||
| # 33 |
97007-05016 9701705016009700705016 |
BOLT(4TW)
|
||||
| # 34 |
92907-05600 9290705600 9290705600 |
WASHER(1RW)
|
||||
| # 35 |
1D7-14426-00 1D71442600 1D71442600 |
DAMPER 2
|
||||
| # 36 |
1D7-85880-00 1D78588001001D78588000 |
LINEAR, CONTROL VALV
|
||||
| # 37 |
1D7-82509-10 1D78250910 1D78250910 |
WIRE, SUB LEAD
|
||||
| # 38 |
5PX-14466-00 5PX1446600 5PX1446600 |
PIPE
|
||||
| # 39 |
1D7-13545-00 1D71354500 1D71354500 |
HOSE 1
|
||||
| # 40 |
1D7-13546-00 1D71354600 1D71354600 |
HOSE 2
|
||||
| # 41 |
1D7-13547-00 1D71354700 1D71354700 |
HOSE 3
|
||||
| # 42 |
1D7-13548-00 1D71354800 1D71354800 |
HOSE, AIR 4
|
||||
| # 43 |
90467-10135 9046710135 9046710135 |
CLIP(3BM)
|
||||
| # 44 |
1D7-13897-00 1D71389700 1D71389700 |
PIPE, AIR
|
||||
| # 45 |
90467-15001 9046715001 9046715001 |
CLIP
|
||||
| # 46 |
90467-17089 9046717128009046717089 |
CLIP(3TB)
|
Yamaha XV1900A
Cilinderinhoud: 1900 Jaar: 2013 Model code 1CR4 Kleur: BLACK METALLIC X
