| # 1 |
1D7-23102-21 1D72310231001D72310221 |
FRONT FORK ASSY (L.H)
|
||||
| # 2 |
1D7-23126-21 1D72312621 1D72312621 |
TUBE, OUTER (LEFT)
|
||||
| # 3 |
1D7-23110-00 1D72311000 1D72311000 |
INNER TUBE COMP.1
|
||||
| # 4 |
1D7-23170-00 1D72317000 1D72317000 |
CYLINDER COMP., FRONT FORK
|
||||
| # 5 |
1D7-23173-00 1D72317300 1D72317300 |
SPINDLE, TAPER
|
||||
| # 6 |
2K8-23158-L0 2K823158L0 2K823158L0 |
GASKET
|
||||
| # 7 |
3R4-23181-L0 3R423181L0 3R423181L0 |
BOLT
|
||||
| # 8 |
5TJ-23125-50 5TJ2312550 5TJ2312550 |
METAL, SLIDE 1
|
||||
| # 9 |
4SS-23146-L0 4SS23146L0 4SS23146L0 |
WASHER, OIL SEAL
|
||||
| # 10 |
1D7-23145-00 1D72314500 1D72314500 |
OIL SEAL
|
||||
| # 11 |
4SS-23153-L0 4SS23153L0 4SS23153L0 |
RING, SNAP
|
||||
| # 12 |
1D7-23144-00 1D72314400 1D72314400 |
SEAL, DUST
|
||||
| # 13 |
1D7-23141-00 1D72314100 1D72314100 |
SPRING, FRONT FORK
|
||||
| # 14 |
1D7-23149-00 1D72314900 1D72314900 |
WASHER, SPRING UPPER
|
||||
| # 15 |
1D7-23118-00 1D72311800 1D72311800 |
SPACER
|
||||
| # 16 |
1D7-23111-00 1D72311100 1D72311100 |
BOLT, CAP
|
||||
| # 17 |
1D7-23188-00 1D72318800 1D72318800 |
O-RING
|
||||
| # 18 |
1D7-23103-21 1D72310331001D72310321 |
FRONT FORK ASSY (R.H)
|
||||
| # 19 |
1D7-23136-21 1D72313621 1D72313621 |
TUBE, OUTER (RIGHT)
|
||||
| # 20 |
1D7-23110-00 1D72311000 1D72311000 |
INNER TUBE COMP.1
|
||||
| # 21 |
1D7-23170-00 1D72317000 1D72317000 |
CYLINDER COMP., FRONT FORK
|
||||
| # 22 |
1D7-23173-00 1D72317300 1D72317300 |
SPINDLE, TAPER
|
||||
| # 23 |
2K8-23158-L0 2K823158L0 2K823158L0 |
GASKET
|
||||
| # 24 |
3R4-23181-L0 3R423181L0 3R423181L0 |
BOLT
|
||||
| # 25 |
5TJ-23125-50 5TJ2312550 5TJ2312550 |
METAL, SLIDE 1
|
||||
| # 26 |
4SS-23146-L0 4SS23146L0 4SS23146L0 |
WASHER, OIL SEAL
|
||||
| # 27 |
1D7-23145-00 1D72314500 1D72314500 |
OIL SEAL
|
||||
| # 28 |
4SS-23153-L0 4SS23153L0 4SS23153L0 |
RING, SNAP
|
||||
| # 29 |
1D7-23144-00 1D72314400 1D72314400 |
SEAL, DUST
|
||||
| # 30 |
1D7-23141-00 1D72314100 1D72314100 |
SPRING, FRONT FORK
|
||||
| # 31 |
1D7-23149-00 1D72314900 1D72314900 |
WASHER, SPRING UPPER
|
||||
| # 32 |
1D7-23118-00 1D72311800 1D72311800 |
SPACER
|
||||
| # 33 |
1D7-23111-00 1D72311100 1D72311100 |
BOLT, CAP
|
||||
| # 34 |
1D7-23188-00 1D72318800 1D72318800 |
O-RING
|
||||
| # 35 |
91314-08040 9131408040 9131408040 |
BOLT, SOCKET
|
||||
| # 36 |
1D7-23400-00 1D72340000 1D72340000 |
STEERING ASSY
|
Contact | |||
| # 37 |
91314-08025 9131408025 9131408025 |
BOLT, SOCKET
|
||||
| # 38 |
1D7-23123-30 1D72312330 1D72312330 |
COVER, LOWER 1
|
||||
| # 39 |
1D7-23133-30 1D72313330 1D72313330 |
COVER, LOWER 2
|
||||
| # 40 |
1D7-23165-00 1D72316500 1D72316500 |
WASHER, FELT
|
||||
| # 41 |
1D7-23357-00 1D72335700 1D72335700 |
NUT
|
||||
| # 42 |
1D7-23163-00 1D72316300 1D72316300 |
GASKET
|
||||
| # 43 |
1D7-23121-30 1D72312130 1D72312130 |
COVER, UPPER 1
|
||||
| # 44 |
1D7-23131-30 1D72313130 1D72313130 |
COVER, UPPER 2
|
||||
| # 45 |
93332-00096 9333200096 9333200096 |
BEARING
|
||||
| # 46 |
4D5-23844-00 4D52384400 4D52384400 |
SEAL
|
||||
| # 47 |
90111-08035 9011108035 9011108035 |
BOLT, HEX. SOCKET BUTTON
|
Yamaha XV1900A
Cilinderinhoud: 1900 Jaar: 2013 Model code 1CR4 Kleur: BLACK METALLIC X
