| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
39P-13750-20 39P1375020 39P1375020 |
THROTTLE BODY ASSY
|
||||
| # 2 |
39P-13761-00 39P1376100 39P1376100 |
INJECTOR
|
||||
| # 3 |
5PS-14147-00 5PS1414700 5PS1414700 |
O-RING
|
||||
| # 4 |
8FP-13556-00 8FP1355600 8FP1355600 |
GASKET, MANIFOLD
|
||||
| # 5 |
5PW-14251-00 5PW1425100 5PW1425100 |
NIPPLE
|
||||
| # 6 |
5YP-14561-00 5YP1456100 5YP1456100 |
O-RING
|
||||
| # 7 |
2C0-14216-00 2C01421600 2C01421600 |
SCREW
|
||||
| # 8 |
5S7-82380-00 5S78238000 5S78238000 |
SENSOR, PRESSURE
|
||||
| # 9 |
39P-82386-10 39P8238610 39P8238610 |
EXTENSION, WIRE HARNESS
|
||||
| # 10 |
39P-1393A-00 39P1393A00 39P1393A00 |
PIPE, INL.
|
||||
| # 11 |
69J-13532-00 69J1353200 69J1353200 |
HOSE, VACUUM SENSING 3
|
||||
| # 12 |
8CC-14216-10 8CC1421610 8CC1421610 |
SCREW
|
||||
| # 13 |
5P0-H5885-00 5P0H588500 5P0H588500 |
THROTTLE SENSOR ASSY
|
||||
| # 14 |
363-14198-00 3631419800 3631419800 |
GASKET
|
||||
| # 15 |
14B-13573-00 14B1357300 14B1357300 |
BOLT 1
|
||||
| # 16 |
39P-14137-00 39P1413700 39P1413700 |
CLIP
|
||||
| # 17 |
5VX-14149-00 5VX1414900 5VX1414900 |
PIPE
|
||||
| # 18 |
5VX-14565-00 5VX1456500 5VX1456500 |
SCREW
|
||||
| # 19 |
8GL-85885-00 8GL8588501008GL8588500 |
SENSITOMETRE (ENS.)
|
||||
| # 20 |
5FL-14216-00 5FL1421600 5FL1421600 |
SCREW
|
||||
| # 21 |
5JW-14349-00 5JW1434900 5JW1434900 |
PIPE
|
||||
| # 22 |
5JW-14104-00 5JW1410400 5JW1410400 |
AIR SCREW SET
|
||||
| # 23 |
39P-14503-00 39P1450300 39P1450300 |
ADJUST SCREW SET
|
||||
| # 24 |
3XV-14251-00 3XV1425100 3XV1425100 |
NIPPLE
|
||||
| # 25 |
5JW-14349-10 5JW1434910 5JW1434910 |
PIPE
|
||||
| # 26 |
8FP-14349-20 8FP1434920 8FP1434920 |
PIPE
|
||||
| # 27 |
68V-24376-00 68V2437600 68V2437600 |
PIPE, JOINT 1
|
||||
| # 28 |
5FL-14348-10 5FL1434810 5FL1434810 |
PIPE 1
|
||||
| # 29 |
39P-14807-00 39P1480700 39P1480700 |
HOSE COMP.
|
||||
| # 30 |
39P-14987-00 39P1498700 39P1498700 |
HOSE
|
||||
| # 31 |
31H-14987-00 31H1498700 31H1498700 |
HOSE
|
||||
| # 32 |
39P-14396-00 39P1439600 39P1439600 |
PIPE
|
||||
| # 33 |
39P-13795-00 39P1379500 39P1379500 |
JOINT, THROTTLE BODY 1
|
||||
| # 34 |
39P-14147-00 39P1414700 39P1414700 |
O-RING
|
||||
| # 35 |
90464-23003 9046423003 9046423003 |
CLAMP
|
||||
| # 36 |
39P-14592-00 39P1459200 39P1459200 |
SCREW
|
||||
| # 37 |
90465-13M11 9046513M11 9046513M11 |
CLAMP (6E5)
|
Yamaha FZ8-S
Cilinderinhoud: 800 Jaar: 2013 Model code 42PE Kleur: MAT GRAY METALLIC 3
