| # 1 |
22K-16111-00 22K1611100 22K1611100 |
GEAR, PRIMARY DRIVE
|
||||
| # 2 |
90208-12015 9020812015 9020812015 |
WASHER 164161190000
|
||||
| # 3 |
90179-12007 9017912007 9017912007 |
NUT
|
||||
| # 4 |
3GB-16150-00 3GB1615000 |
PRIMARY DRIVEN GEAR COMP.
|
Contact | |||
| # 5 |
93341-22302 9334122302 9334122302 |
BEARING, THRUST
|
Contact | |||
| # 6 |
93450-42112 9345042112 9345042112 |
CIRCLIP(38A)
|
Contact | |||
| # 7 |
22F-16153-40 22F1615340 22F1615340 |
WASHER, THRUST (1.7T)
|
Contact | |||
| # 8 |
93505-08030 9350508030 9350508030 |
BALL (5/8INCH) (527 CKD)
|
||||
| # 9 |
22K-16520-00 22K1652000 22K1652000 |
PLATE, THRUST WEIGHT
|
Contact | |||
| # 10 |
517-16524-10 5171652410 5171652410 |
PLATE, CLUTCH 1
|
||||
| # 10 |
517-16524-20 5171652420 5171652420 |
PLATE, CLUTCH 2
|
||||
| # 10 |
517-16524-30 5171652430 5171652430 |
PLATE, CLUTCH 3
|
||||
| # 11 |
90501-105A5 90501105A5 90501105A5 |
SPRING, COMPRESSION(55X)
|
||||
| # 12 |
22F-16550-00 22F1655000 22F1655000 |
PRESSURE PLATE ASSY
|
Contact | |||
| # 13 |
22K-16590-00 22K1659000 22K1659000 |
PUSH PLATE ASSY
|
Contact | |||
| # 14 |
93420-26077 9342026077 9342026077 |
CIRCLIP(2FL)
|
||||
| # 15 |
93451-08094 9345108094 9345108094 |
CIRCLIP (22F)
|
||||
| # 16 |
22K-W1657-00 22KW165700 |
CLUTCH BOSS ASSY
|
Contact | |||
| # 17 |
22F-16524-01 22F1652401 22F1652401 |
PLATE, CLUTCH 1
|
||||
| # 18 |
3E5-16521-00 3E51652100 3E51652100 |
PLATE, FRICTION
|
||||
| # 19 |
22F-16521-00 22F1652100 22F1652100 |
PLATE, FRICTION
|
||||
| # 20 |
90501-135A4 90501135A4 90501135A4 |
SPRING, COMPRESSION(55X)
|
||||
| # 21 |
122-16164-00 1221616400 1221616400 |
PLATE, THRUST
|
||||
| # 22 |
90560-17146 9056017146 9056017146 |
SPACER (517)
|
||||
| # 23 |
90215-14249 9021514249 9021514249 |
WASHER, LOCK(55X)
|
||||
| # 24 |
90170-14284 9017014284 9017014284 |
NUT (5H0)
|
||||
| # 25 |
22F-16357-01 22F1635701 22F1635701 |
ROD, PUSH
|
||||
| # 26 |
22K-16356-00 22K1635600 22K1635600 |
ROD, PUSH 1
|
Contact | |||
| # 27 |
90151-06070 9015106070 9015106070 |
SCREW, COUNTERSUNK
|
Contact | |||
| # 28 |
93104-10076 9310410076 9310410076 |
OIL SEAL (22F)
|
Contact | |||
| # 29 |
93102-07292 9310207292 9310207292 |
OIL SEAL (22F)
|
||||
| # 30 |
22F-16362-01 22F1636201 22F1636201 |
LEVER, PUSH 2
|
Contact | |||
| # 31 |
22F-16342-01 22F1634201 22F1634201 |
LEVER, PUSH
|
Contact | |||
| # 32 |
90387-062G9 90387062G9 90387062G9 |
COLLAR (22F)
|
Contact | |||
| # 33 |
90387-062G8 90387062G8 90387062G8 |
COLLAR (22F)
|
Contact | |||
| # 34 |
99001-04600 9908004600009900104600 |
CIRCLIP (EU0)
|
||||
| # 35 |
22F-16382-00 22F1638200 22F1638200 |
AXLE, PUSH LEVER
|
||||
| # 36 |
92902-06600 9299006600009290206600 |
WASHER, PLAIN (646)
|
||||
| # 37 |
95302-06600 9538006600009530206600 |
NUT(661)
|
||||
| # 38 |
22F-16399-00 22F1639900 22F1639900 |
GUIDE, PUSH ROD
|
Contact | |||
| # 39 |
98502-06016 9858006016009850206016 |
SCREW PAN HEAD
|
||||
| # 40 |
22F-16383-00 22F1638300 22F1638300 |
SPRING, CLUTCH BOSS
|
Contact | |||
| # 41 |
90380-07118 9038007118 9038007118 |
BUSH, SOLID (22F)
|
Contact | |||
| # 42 |
22F-16163-00 22F1616300 22F1616300 |
WASHER
|
Contact | |||
| # 43 |
93440-11128 9344011128 9344011128 |
CIRCLIP (22F)
|
Contact |
Yamaha YFM80W YFM80
Cilinderinhoud: 80 Jaar: 2008 Model code 5THN Kleur: DEEP PURPLISH BLUE SOLID E
