| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
1PE-F1871-00 1PEF187100 1PEF187100 |
TANK, RECOVERY
|
||||
| # 2 |
1S3-21875-00 1S32187500 1S32187500 |
CAP
|
||||
| # 3 |
90445-09M30 9044509021009044509M30 |
HOSE (L865)
|
||||
| # 4 |
90445-09777 90445090F6009044509777 |
HOSE (L1500)
|
||||
| # 5 |
90119-06152 9011906152 9011906152 |
BOLT, WITH WASHER
|
||||
| # 6 |
904670800300 904670800300904670800300 |
CLIP 101235600
|
||||
| # 7 |
90464-23041 9046425267009046423041 |
CLAMP
|
||||
| # 8 |
1S3-21750-10 1S32175010 1S32175010 |
OIL TANK ASSY
|
||||
| # 9 |
5LP-21761-01 5LP2176101 5LP2176101 |
GAUGE, LEVEL
|
||||
| # 10 |
93210-21190 9321021190 9321021190 |
O-RING
|
||||
| # 11 |
95812-08016 9010508X15009581208016 |
BLT, HEX, 1/4-20X5/8
|
||||
| # 12 |
90201-082A6 90201082A6 90201082A6 |
WASHER, PLATE (4L0)
|
||||
| # 13 |
90480-13459 9048013459 9048013459 |
GROMMET(1VJ)
|
||||
| # 14 |
90387-06205 9038706205 9038706205 |
COLLAR
|
||||
| # 15 |
95812-06020 9581706020009581206020 |
BOLT, FLANGE
|
||||
| # 16 |
90480-24004 9048024004 9048024004 |
GROMMET
|
||||
| # 17 |
90467-100A1 90467100A1 90467100A1 |
CLIP
|
||||
| # 18 |
90445-11034 9044511034 9044511034 |
HOSE (L147)
|
||||
| # 19 |
2LS-13465-00 2LS1346510002LS1346500 |
HOSE, OIL 2
|
||||
| # 20 |
93210-10197 9321010197 9321010197 |
O-RING (371)
|
||||
| # 21 |
95022-06016 9502206016 9502206016 |
BOLT, FLANGE
|
||||
| # 22 |
90450-22017 9045022M14009045022017 |
HOSE CLAMP ASSY(64X)
|
||||
| # 23 |
1S3-13464-10 1S31346411001S31346410 |
DURITE A HUILE
|
||||
| # 24 |
93210-16629 9321016629 9321016629 |
O-RING (26H)
|
||||
| # 25 |
91312-06016 9131206016 |
BOLT, SOCKET
|
Contact |
Yamaha YFM700RYFM700RSF
Cilinderinhoud: 700 Jaar: 2015 Model code B463 Kleur: YAMAHA BLACK
