| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
13S-21110-10 13S2111010 13S2111010 |
FRAME COMP.
|
Contact | |||
| # 2 |
13S-21190-10 13S2119010 13S2119010 |
REAR FRAME COMP.
|
||||
| # 3 |
13S-2585H-00 13S2585H090013S2585H00 |
SCREW, SET
|
||||
| # 4 |
95024-10040 9502410040 9502410040 |
BOLT, SMALL FLANGE
|
||||
| # 5 |
13S-21414-00 13S2141400 13S2141400 |
BOSS, ENGINE MOUNT
|
||||
| # 6 |
13S-21424-00 13S2142400 13S2142400 |
BOSS, ENGINE MOUNT
|
||||
| # 7 |
90105-12228 9010512228 9010512228 |
BOLT, WASHER BASED (14A)
|
||||
| # 8 |
90179-12004 9017912004 9017912004 |
NUT
|
||||
| # 9 |
90338-15004 9033815004 9033815004 |
PLUG
|
||||
| # 10 |
2C0-24182-00 2C02418200 2C02418200 |
DAMPER, LOCATING 2
|
||||
| # 11 |
2C0-21486-00 2C02148600 2C02148600 |
DAMPER 2
|
||||
| # 12 |
13S-21435-00 13S2143500 13S2143500 |
BRACKET, MUFFLER 1
|
||||
| # 13 |
90105-08171 9581208020009010508171 |
BOLT, FLANGE
|
||||
| # 14 |
13S-2110M-00 13S2110M00 13S2110M00 |
COVER ASSY 1
|
||||
| # 15 |
13S-2174X-00 13S2174X00 13S2174X00 |
DAMPER
|
||||
| # 16 |
2C0-2174Y-00 2C02174Y00 2C02174Y00 |
DAMPER
|
||||
| # 17 |
2C0-21746-00 2C02174600 2C02174600 |
DAMPER
|
||||
| # 18 |
90269-07010 9026907010 9026907010 |
RIVET
|
||||
| # 19 |
2C0-8258J-00 2C08258J00 2C08258J00 |
HOUSING, CONNECTEUR 1
|
||||
| # 20 |
2C0-22241-00 2C02224100 2C02224100 |
BOLT 1
|
||||
| # 21 |
2C0-21279-00 2C02127900 2C02127900 |
PLUG, BLIND
|
||||
| # 23 |
2C0-21566-00 2C02156600 2C02156600 |
TAPE, 1
|
||||
| # 24 |
2C0-21567-00 2C02156700 2C02156700 |
TAPE, 2
|
||||
| # 25 |
13S-21566-00 13S2156600 13S2156600 |
TAPE, 1
|
||||
| # 26 |
13S-21567-00 13S2156700 13S2156700 |
TAPE, 2
|
||||
| # 27 |
13S-2111D-00 13S2111D00 13S2111D00 |
SEAL 1
|
||||
| # 28 |
2C0-21566-00 2C02156600 2C02156600 |
TAPE, 1
|
||||
| # 29 |
13S-21746-00 13S2174600 13S2174600 |
DAMPER
|
||||
| # 30 |
13S-2833A-00 13S2833A010013S2833A00 |
SUPPORT 7
|
||||
| # 31 |
90480-10003 9048010003 9048010003 |
GROMMET
|
||||
| # 32 |
90387-06048 9038706048 9038706048 |
COLLAR
|
||||
| # 33 |
90183-05076 90183050A6009018305076 |
NUT, SPRING
|
||||
| # 34 |
95802-06020 9581706020009580206020 |
BOLT, FLANGE
|
||||
| # 35 |
13S-12679-00 13S1267900 13S1267900 |
DAMPER, SHROUD 6
|
||||
| # 36 |
13S-2833E-00 13S2833E00 13S2833E00 |
BRACET 8
|
||||
| # 37 |
90480-10003 9048010003 9048010003 |
GROMMET
|
||||
| # 38 |
90387-06048 9038706048 9038706048 |
COLLAR
|
||||
| # 39 |
90183-05076 90183050A6009018305076 |
NUT, SPRING
|
||||
| # 40 |
95802-06020 9581706020009580206020 |
BOLT, FLANGE
|
Yamaha YZF-R6
Cilinderinhoud: 600 Jaar: 2013 Model code 1JSU Kleur: DEEP PURPLISH BLUE METALLIC C
