| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
5C3-E4610-10 5C3E461010 5C3E461010 |
EXT.PIPE 50CC
|
||||
| # 2 |
5C3-E4445-00 5C3E444500 5C3E444500 |
GROMMET
|
||||
| # 3 |
5C3-E4779-00 5C3E477900 5C3E477900 |
COLLAR
|
||||
| # 4 |
5C3-E4708-01 5C3E470810005C3E470801 |
PROTECTOR ASSY
|
||||
| # 5 |
90387-06X46 9038706X46 9038706X46 |
COLLAR
|
||||
| # 6 |
90480-12X05 9048012X05 9048012X05 |
GROMMET
|
||||
| # 7 |
90111-06015 9011106015 9011106015 |
BOLT
|
||||
| # 8 |
90111-06X25 9011106X25 9011106X25 |
BOLT, HEX. SOCKET B
|
||||
| # 9 |
90201-06X12 9020106X12 9020106X12 |
WASHER, PLATE
|
||||
| # 10 |
90201-06078 9020106078 9020106078 |
WASHER, PLATE
|
||||
| # 11 |
90201-05015 9020105015 9020105015 |
WASHER, PLATE
|
||||
| # 12 |
1P4-E4613-00 1P4E461300 1P4E461300 |
GASKET, EXHAUST PI
|
||||
| # 13 |
95607-08200 9018508169009560708200 |
NUT, SELF-LOCKING
|
||||
| # 14 |
90105-08X19 9010508X19 9010508X19 |
BLT, HEX, 1/4-20X5/8
|
||||
| # 15 |
90387-08X07 9038708X07 9038708X07 |
COLLAR
|
||||
| # 16 |
5C3-E4881-10 5C3E488110 5C3E488110 |
HOSE, BEND 1
|
||||
| # 17 |
90467-16X00 9046716X00 9046716X00 |
CLIP
|
||||
| # 18 |
5C3-E4803-00 5C3E480300 5C3E480300 |
AIR INDUCTION SYST
|
||||
| # 19 |
90119-06X01 9011906X01 9011906X01 |
BOLT, WITH WASHER
|
Contact | |||
| # 20 |
5C2-E4882-00 5C2E488200 5C2E488200 |
HOSE, BEND 2
|
||||
| # 21 |
90468-08104 9046808104 9046808104 |
CLIP
|
||||
| # 22 |
5MR-E4806-00 5MRE480600 5MRE480600 |
AIR FILTER CASE AS
|
Yamaha YN50F
Cilinderinhoud: 50 Jaar: 2012 Model code 5C39 Kleur: DARK VIOLET METALLIC C
