| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
1WD-E5411-00 1WDE541100 1WDE541100 |
COVER, CRANKCASE 1
|
||||
| # 2 |
91312-05012 9131705012009131205012 |
BOLT, SOCKET
|
||||
| # 3 |
92014-08012 9201408012 9201408012 |
BOLT, BUTTON HEAD
|
||||
| # 4 |
90430-08143 9043008143 9043008143 |
GASKET (256-11198-00)
|
||||
| # 5 |
90340-32819 9034032819 9034032819 |
PLUG, STRAIGHT SCR
|
||||
| # 6 |
93210-32816 9321032816 9321032816 |
O-RING
|
||||
| # 7 |
1WD-E5451-00 1WDE545100 1WDE545100 |
GASKET, CRANKCASE
|
||||
| # 8 |
99530-08012 9953008012 9953008012 |
PIN, DOWEL(6G8)
|
||||
| # 9 |
95022-06025 9502206025 9502206025 |
BOLT, FLANGE
|
||||
| # 10 |
1WD-E5461-00 1WDE546100 1WDE546100 |
GASKET, CRANKCASE
|
||||
| # 11 |
99530-08012 9953008012 9953008012 |
PIN, DOWEL(6G8)
|
||||
| # 12 |
95022-06025 9502206025 9502206025 |
BOLT, FLANGE
|
||||
| # 13 |
95022-06050 9502206050 9502206050 |
BOLT, FLANGE
|
||||
| # 14 |
2MS-E5441-00 2MSE544100 2MSE544100 |
HOLDER, CLUTCH CAB
|
||||
| # 15 |
91312-06025 9131706025009131206025 |
BOLT, SOCKET
|
||||
| # 16 |
1WD-E5413-10 1WDE541310 1WDE541310 |
COVER
|
||||
| # 17 |
1WD-E5462-00 1WDE546200 1WDE546200 |
GASKET, CRANKCASE
|
||||
| # 18 |
95022-06025 9502206025 9502206025 |
BOLT, FLANGE
|
||||
| # 19 |
90462-08812 9046208812 9046208812 |
CLAMP
|
||||
| # 20 |
90462-08806 9046208806 9046208806 |
CLAMP
|
||||
| # 21 |
1WD-E5377-00 1WDE537700 1WDE537700 |
GUIDE, INLET
|
||||
| # 22 |
1WD-E5418-00 1WDE541800 1WDE541800 |
COVER, CHAIN CASE
|
||||
| # 23 |
95022-06025 9502206025 9502206025 |
BOLT, FLANGE
|
||||
| # 24 |
90462-08225 9046208225 9046208225 |
CLAMP(4AJ)
|
