| # 1 |
1SM-14611-00 1SM1461100 1SM1461100 |
PIPE, EXHAUST 1
|
||||
| # 2 |
1SL-14628-00 1SL1462800 1SL1462800 |
PROTECTOR, EXHAUST PIPE
|
||||
| # 3 |
90201-05017 9020105017 9020105017 |
WASHER, PLATE
|
||||
| # 4 |
98980-06008 9898006008 9898006008 |
SCREW, BIND(2TV)
|
||||
| # 5 |
5NL-14613-00 5NL1461300 5NL1461300 |
GASKET, EXHAUST PIPE
|
||||
| # 6 |
95702-08500 9570408500009570208500 |
NUT, FLANGE
|
||||
| # 7 |
1SM-14621-00 1SM1462100 1SM1462100 |
PIPE, EXHAUST 2
|
||||
| # 8 |
5PX-14755-00 5PX1475500 5PX1475500 |
GASKET, SILENCER
|
||||
| # 9 |
1SL-1463B-00 1SL1463B00 1SL1463B00 |
PROTECTOR, EXT. PIPE 2
|
||||
| # 10 |
90201-05017 9020105017 9020105017 |
WASHER, PLATE
|
||||
| # 11 |
98980-06008 9898006008 9898006008 |
SCREW, BIND(2TV)
|
||||
| # 12 |
1SM-14788-00 1SM1478800 1SM1478800 |
BAND, SILENCER
|
||||
| # 13 |
95024-08040 9502408040 9502408040 |
BOLT, FLANGE(4KG)
|
||||
| # 14 |
1SM-14639-00 1SM1463900 1SM1463900 |
STAY, EXHAUST PIPE 1
|
||||
| # 15 |
5VY-14747-00 5VY1474700 5VY1474700 |
DAMPER, MUFFLER
|
||||
| # 16 |
90105-08137 9010508137 9010508137 |
BOLT, FLANGE
|
||||
| # 17 |
90201-08061 9020108061 9020108061 |
WASHER, PLATE
|
||||
| # 18 |
90387-08081 9038708081 9038708081 |
COLLAR
|
||||
| # 19 |
1SM-14750-10 1SM14750A0001SM1475010 |
SILENCER ASSY
|
||||
| # 20 |
90110-05064 9011005066009011005064 |
BOLT, HEXAGON SOCKET HEAD
|
||||
| # 21 |
90267-48121 9026748910009026748121 |
RIVET, MONEL (F14)
|
||||
| # 22 |
1SM-1466G-00 1SM1466G00 1SM1466G00 |
BODY, SILENCER
|
||||
| # 23 |
1SM-1469A-10 1SM1469A10 1SM1469A10 |
FIBER
|
||||
| # 24 |
1SM-1477E-10 1SM1477E10 1SM1477E10 |
FIBER 2
|
||||
| # 25 |
1SL-1469F-00 1SL1469F00 1SL1469F00 |
FIBER
|
||||
| # 26 |
1SL-1477G-00 1SL1477G00 1SL1477G00 |
FIBER 4
|
||||
| # 27 |
1SL-1477H-00 1SL1477H00 1SL1477H00 |
FIBER 5
|
||||
| # 28 |
1SL-14714-00 1SL1471400 1SL1471400 |
GASKET, MUFFLER
|
||||
| # 29 |
1SL-14715-00 1SL1471500 1SL1471500 |
BAND, MUFFLER
|
||||
| # 30 |
95024-08040 9502408040 9502408040 |
BOLT, FLANGE(4KG)
|
||||
| # 31 |
90105-08230 9010508230 9010508230 |
BOLT, FLANGE
|
||||
| # 32 |
90119-08133 9011908133 9011908133 |
BOLT, WITH WASHER
|
Yamaha YFM700FWAD
Cilinderinhoud: 250 Jaar: 2015 Model code B293 Kleur: DEEP PURPLISH BLUE SOLID E
