| # 1 |
5UM-23102-90-00 5UM231029000 5UM231029000 |
FRONT FORK ASSY (L.H)
|
||||
| # 1 |
5UM-23102-A0-00 5UM23102A000 5UM23102A000 |
FOURCHE AVANT COMPLETE (G)
|
Contact | |||
| # 1 |
5UM-23102-L0-00 5UM23102L000 5UM23102L000 |
FOURCHE AVANT COMPLETE (G)
|
Contact | |||
| # 2 |
5TJ-23136-L0-00 5TJ23136L000 5TJ23136L000 |
.BAS DE FOURCHE(DROIT) BAS DE FOURCHE(DROIT)
|
Contact | |||
| # 3 |
5TJ-23120-L0-00 5TJ23120L000 5TJ23120L000 |
.TUBE DE FOURCHE NUE TUBE DE FOURCHE NUE
|
Contact | |||
| # 3 |
5TJ-23120-90-00 5TJ231209000 |
INNER TUBE COMP.2
|
Contact | |||
| # 4 |
5XE-23171-L0-00 5XE23171L000 5XE23171L000 |
PISTON, FRONT FORK
|
||||
| # 5 |
5XE-23125-L0-00 5XE23125L000 5XE23125L000 |
METAL, SLIDE 1
|
||||
| # 6 |
5XE-23146-L0-00 5XE23146L000 5XE23146L000 |
WASHER, OIL SEAL
|
||||
| # 7 |
1C3-23145-L0-00 1C323145L000 1C323145L000 |
OIL SEAL
|
||||
| # 8 |
5XE-23153-L0-00 5XE23153L000 5XE23153L000 |
RING, SNAP
|
||||
| # 9 |
5XE-23144-L0-00 5XE23144L000 5XE23144L000 |
SEAL, DUST
|
||||
| # 10 |
5TJ-23170-80-00 5TJ231708000 5TJ231708000 |
.CYLINDRE DE FOURCHE AV CYLINDRE DE FOURCHE AV
|
Contact | |||
| # 10 |
5TJ-23170-90-00 5TJ231709000 5TJ231709000 |
.CYLINDRE DE FOURCHE AV CYLINDRE DE FOURCHE AV
|
Contact | |||
| # 11 |
5TJ-23142-L0-00 5TJ23142L000 5TJ23142L000 |
SEAT, SPRING UPPER
|
Contact | |||
| # 12 |
5HD-23393-L0-00 5HD23393L000 5HD23393L000 |
NUT, SPECIAL
|
||||
| # 13 |
5UM-2316A-80-00 5UM2316A8000 5UM2316A8000 |
.CLAPET CLAPET
|
Contact | |||
| # 13 |
5UM-2316A-90-00 5UM2316A9000 5UM2316A9000 |
.CLAPET CLAPET
|
Contact | |||
| # 13 |
5UM-2316A-A0-00 5UM2316AA000 5UM2316AA000 |
.CLAPET CLAPET
|
Contact | |||
| # 14 |
3JD-23158-L0-00 3JD23158L000 3JD23158L000 |
GASKET
|
Contact | |||
| # 15 |
5TJ-23141-90-00 5TJ2314120005TJ231419000 |
SPRING, FRONT FORK
|
||||
| # 15 |
5UM-23141-A0-00 5UM23141A000 5UM23141A000 |
.RESSORT, FOURCHE AVANT RESSORT, FOURCHE AVANT
|
Contact | |||
| # 16 |
5XE-23111-L0-00 5XE23111L000 5XE23111L000 |
BOLT, CAP
|
||||
| # 17 |
5MV-23195-L0-00 5MV23195L000 5MV23195L000 |
RUBBER
|
||||
| # 18 |
5TJ-23149-L0-00 5TJ23149L000 5TJ23149L000 |
WASHER, SPRING UPPER
|
Contact | |||
| # 19 |
5TJ-23118-L0-00 5TJ23118L000 5TJ23118L000 |
SPACER
|
Contact | |||
| # 20 |
1C3-2314F-L0-00 1C32314FL000 1C32314FL000 |
PROTECTER GUIDE COMP., 1
|
Contact | |||
| # 21 |
5UM-23103-90-00 5UM231039000 5UM231039000 |
FRONT FORK ASSY (R.H)
|
||||
| # 21 |
5UM-23103-A0-00 5UM23103A000 5UM23103A000 |
FOURCHE AVANT COMPLETE (D)
|
Contact | |||
| # 21 |
5UM-23103-L0-00 5UM23103L000 5UM23103L000 |
FOURCHE AVANT COMPLETE (D)
|
Contact | |||
| # 22 |
5TJ-23136-L0-00 5TJ23136L000 5TJ23136L000 |
.BAS DE FOURCHE(DROIT) BAS DE FOURCHE(DROIT)
|
Contact | |||
| # 23 |
5TJ-23110-90-00 5TJ231109000 5TJ231109000 |
.TUBE DE FOURCHE NU TUBE DE FOURCHE NU
|
Contact | |||
| # 23 |
5TJ-23110-L0-00 5TJ23110L000 5TJ23110L000 |
.TUBE DE FOURCHE NU TUBE DE FOURCHE NU
|
Contact | |||
| # 24 |
5XE-23171-L0-00 5XE23171L000 5XE23171L000 |
PISTON, FRONT FORK
|
||||
| # 25 |
5XE-23125-L0-00 5XE23125L000 5XE23125L000 |
METAL, SLIDE 1
|
||||
| # 26 |
5XE-23146-L0-00 5XE23146L000 5XE23146L000 |
WASHER, OIL SEAL
|
||||
| # 27 |
1C3-23145-L0-00 1C323145L000 1C323145L000 |
OIL SEAL
|
||||
| # 28 |
5XE-23153-L0-00 5XE23153L000 5XE23153L000 |
RING, SNAP
|
||||
| # 29 |
5XE-23144-L0-00 5XE23144L000 5XE23144L000 |
SEAL, DUST
|
||||
| # 30 |
5TJ-23170-80-00 5TJ231708000 5TJ231708000 |
.CYLINDRE DE FOURCHE AV CYLINDRE DE FOURCHE AV
|
Contact | |||
| # 30 |
5TJ-23170-90-00 5TJ231709000 5TJ231709000 |
.CYLINDRE DE FOURCHE AV CYLINDRE DE FOURCHE AV
|
Contact | |||
| # 31 |
5TJ-23142-L0-00 5TJ23142L000 5TJ23142L000 |
SEAT, SPRING UPPER
|
Contact | |||
| # 32 |
5HD-23393-L0-00 5HD23393L000 5HD23393L000 |
NUT, SPECIAL
|
||||
| # 33 |
5UM-2316A-80-00 5UM2316A8000 5UM2316A8000 |
.CLAPET CLAPET
|
Contact | |||
| # 33 |
5UM-2316A-90-00 5UM2316A9000 5UM2316A9000 |
.CLAPET CLAPET
|
Contact | |||
| # 33 |
5UM-2316A-A0-00 5UM2316AA000 5UM2316AA000 |
.CLAPET CLAPET
|
Contact | |||
| # 34 |
3JD-23158-L0-00 3JD23158L000 3JD23158L000 |
GASKET
|
Contact | |||
| # 35 |
5TJ-23141-90-00 5TJ2314120005TJ231419000 |
SPRING, FRONT FORK
|
||||
| # 35 |
5UM-23141-A0-00 5UM23141A000 5UM23141A000 |
.RESSORT, FOURCHE AVANT RESSORT, FOURCHE AVANT
|
Contact | |||
| # 36 |
5XE-23111-L0-00 5XE23111L000 5XE23111L000 |
BOLT, CAP
|
||||
| # 37 |
5MV-23195-L0-00 5MV23195L000 5MV23195L000 |
RUBBER
|
||||
| # 38 |
5TJ-23149-L0-00 5TJ23149L000 5TJ23149L000 |
WASHER, SPRING UPPER
|
Contact | |||
| # 39 |
5TJ-23118-L0-00 5TJ23118L000 5TJ23118L000 |
SPACER
|
Contact | |||
| # 40 |
1C3-2314F-L0-00 1C32314FL000 1C32314FL000 |
PROTECTER GUIDE COMP., 1
|
Contact | |||
| # 41 |
5NY-23346-L0-00 5NY23346L000 5NY23346L000 |
BOLT 1
|
||||
| # 42 |
5TJ-23340-L0-00 5TJ23340L000 5TJ23340L000 |
UNDER BRACKET COMP.
|
Contact | |||
| # 43 |
95027-08040-00 950270804000 950270804000 |
BOLT, FLANGE(4MY)
|
||||
| # 44 |
5TJ-2315J-80-00 5TJ2315J8000 5TJ2315J8000 |
PROTECTOR 2
|
||||
| # 45 |
4XL-2153A-10-00 4XL2153A11004XL2153A1000 |
EMBLEME, YAMAHA
|
||||
| # 46 |
1C3-2315H-00-00 1C32315H10001C32315H0000 |
PROTECTOR 1
|
||||
| # 47 |
4XL-2153A-10-00 4XL2153A11004XL2153A1000 |
EMBLEME, YAMAHA
|
||||
| # 48 |
3SP-23356-L0-00 3SP23356L000 3SP23356L000 |
BOLT 2
|
||||
| # 49 |
1C3-23466-00-00 1C32346650001C3234660000 |
CLAMP
|
||||
| # 50 |
1C3-23467-00-00 1C32346750001C3234670000 |
CLAMP
|
||||
| # 51 |
95707-06500-00 957070650000 957070650000 |
NUT, FLANGE(4MV)
|
Yamaha WR250FT
Cilinderinhoud: 250 Jaar: 2005 Model code 5UMA Kleur: DEEP PURPLISH BLUE SOLID E
