Winkelwagen
| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
3P6-15100-00 9999904259003P61510000 |
CRANKCASE ASSY SET
|
||||
| # 2 |
99530-10014 9953010014 9953010014 |
PIN, DOWEL
|
||||
| # 3 |
99530-10114 9953010114 9953010114 |
PIN, DOWEL(3VD)
|
||||
| # 4 |
90119-09001 9011909001 9011909001 |
BOLT, WITH WASHER
|
||||
| # 5 |
95812-06045 9581706045009581206045 |
BOLT, FLANGE
|
||||
| # 6 |
95812-06055 9581206055 9581206055 |
BOLT, FLANGE
|
||||
| # 7 |
90105-06079 9581206055009010506079 |
BOLT, FLANGE
|
||||
| # 8 |
95812-06065 9581206065 9581206065 |
BOLT, FLANGE
|
||||
| # 9 |
95812-06080 9581206080 9581206080 |
BOLT, FLANGE
|
||||
| # 10 |
95812-08050 9581708050009581208050 |
BOLT, FLANGE
|
||||
| # 11 |
95812-08065 9581408065009581208065 |
BOLT, FLANGE
|
||||
| # 12 |
90109-06168 9010906168 9010906168 |
BOLT
|
||||
| # 13 |
2H7-15361-00 2H71536100 2H71536100 |
GAUGE, LEVEL
|
||||
| # 14 |
5JW-11165-00 5JW1116501005JW1116500 |
PLAQUE, RENIFLARD
|
||||
| # 15 |
90110-06182 9131206012009011006182 |
BOLT(3DM)
|
||||
| # 16 |
5JW-11145-00 5JW1114500 5JW1114500 |
PLATE, BREATHER 2
|
||||
| # 17 |
90149-06158 9014906156009014906158 |
SCREW
|
||||
| # 18 |
5JW-15412-00 5JW1541200 5JW1541200 |
COVER, OIL PUMP
|
||||
| # 19 |
90110-06182 9131206012009011006182 |
BOLT(3DM)
|
||||
| # 20 |
90338-20263 9033820263 9033820263 |
PLUG
|
||||
| # 21 |
93210-16314 9321016314 9321016314 |
O-RING (1J7)
|
||||
| # 22 |
4H7-15189-00 4H71518900 4H71518900 |
PLUG
|
||||
| # 23 |
93210-207A0 93210208020093210207A0 |
O-RING
|
||||
| # 24 |
90338-16262 9033816262 9033816262 |
PLUG
|
||||
| # 25 |
93210-12790 9321012790 9321012790 |
O-RING(3LD)
|
||||
| # 26 |
5JW-15191-00 5JW1519100 5JW1519100 |
PLATE
|
||||
| # 27 |
90149-06158 9014906156009014906158 |
SCREW
|
||||
| # 28 |
5JW-15189-00 5JW1518900 5JW1518900 |
PLUG
|
||||
| # 29 |
90105-06080 9581206014009010506080 |
BOLT, FLANGE
|
||||
| # 30 |
5JW-15645-00 5JW1564500 5JW1564500 |
SHIM, KICK SHAFT
|
||||
| # 31 |
5JW-15113-00 5JW1511300 5JW1511300 |
PLATE
|
||||
| # 32 |
90105-06080 9581206014009010506080 |
BOLT, FLANGE
|
||||
| # 33 |
2D2-1547A-00 2D21547A00 2D21547A00 |
BASE, SENSOR
|
||||
| # 34 |
93101-10001 9310110090009310110001 |
OIL SEAL (J10)
|
||||
| # 35 |
93210-21001 9321021001 9321021001 |
O-RING
|
||||
| # 36 |
90110-05033 9131205025009011005033 |
BOLT
|
Yamaha FJR1300AS
Cilinderinhoud: 1300 Jaar: 2011 Model code 1DA9 Kleur: BLACK METALLIC X
