| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
14B-Y2410-00-04 14BW2410010414BY24100004 |
FUEL TANK COMP.
|
||||
| # 2 |
1KB-24240-00 1KB2424000 1KB2424000 |
GRAPHIC SET
|
||||
| # 3 |
5SL-2413B-00 5SL2413B00 5SL2413B00 |
EMBLEM
|
||||
| # 4 |
91312-06016 9131206016 |
BOLT, SOCKET
|
Contact | |||
| # 5 |
4BP-24188-00 1HX2418801004BP2418800 |
MOLD, FUEL TANK
|
||||
| # 6 |
5VY-24183-00 5VY2418300 5VY2418300 |
DAMPER, LOCATING 3
|
||||
| # 7 |
14B-24191-10 14B2419110 14B2419110 |
BRACKET, FUEL TANK 1
|
||||
| # 8 |
5VY-24181-00 5VY2418100 5VY2418100 |
DAMPER, LOCATING 1
|
||||
| # 9 |
90480-10542 9048010542 9048010542 |
GROMMET(3XV)
|
||||
| # 10 |
14B-21161-00 14B2116100 14B2116100 |
HOLDER, CABLE
|
||||
| # 11 |
90387-06143 9038706143 9038706143 |
COLLAR
|
||||
| # 12 |
14B-24192-10 14B2419210 14B2419210 |
BRACKET, FUEL TANK 2
|
||||
| # 13 |
5VY-24181-00 5VY2418100 5VY2418100 |
DAMPER, LOCATING 1
|
||||
| # 14 |
90480-10542 9048010542 9048010542 |
GROMMET(3XV)
|
||||
| # 15 |
14B-21162-00 14B2116200 14B2116200 |
HOLDER, CLUTCH CABLE
|
||||
| # 16 |
90119-06262 9011906262 9011906262 |
BOLT, WITH WASHER
|
||||
| # 17 |
90110-06378 9011006378 9011006378 |
BOLT, HEXAGON SOCKET HEAD
|
||||
| # 18 |
14B-2413Y-10 14B2413Y10 14B2413Y10 |
BRACKET, TANK FITTING
|
||||
| # 19 |
5SL-24183-00 5SL2418300 5SL2418300 |
DAMPER, LOCATING 3
|
||||
| # 20 |
90387-06055 9038706055 9038706055 |
COLLAR
|
||||
| # 21 |
90110-06163 9011006163 9011006163 |
BOLT, HEXAGON SOCKET HEAD
|
||||
| # 22 |
39P-24602-00 39P2460200 39P2460200 |
CAP ASSY
|
||||
| # 23 |
90110-05112 9011005112 9011005112 |
BOLT, HEXAGON SOCKET HEAD(1FM)
|
||||
| # 24 |
91312-05010 9131205010 9131205010 |
BOLT
|
||||
| # 25 |
14B-13907-00 14B13907220014B1390700 |
POMPE A CARBURANT CO
|
||||
| # 26 |
13S-24491-00 13S2449100 13S2449100 |
BRACKET, FUEL PUMP
|
||||
| # 27 |
14B-24135-00 14B2413500 14B2413500 |
CLAMP 1
|
||||
| # 28 |
90110-05030 9131205008009011005030 |
BOLT
|
||||
| # 29 |
19B-24486-00 19B24486010019B2448600 |
O-RING
|
||||
| # 30 |
90110-05028 9011005028 9011005028 |
BOLT, HEXAGON SOCKET HEAD
|
||||
| # 31 |
14B-24312-00 14B2431200 14B2431200 |
PIPE 2
|
||||
| # 32 |
90464-09M31 9046409M31 9046409M31 |
CLAMP(6M7)
|
||||
| # 33 |
14B-24313-00 14B2431300 14B2431300 |
PIPE 3
|
||||
| # 34 |
14B-24314-00 14B2431400 14B2431400 |
PIPE 4
|
||||
| # 35 |
90467-09006 90467090A2009046709006 |
CLIP
|
||||
| # 36 |
14B-Y210A-00-2X 14BY210A002X 14BY210A002X |
COVER, TOP
|
||||
| # 37 |
1KB-24230-00 1KB2423001001KB2423000 |
GRAPHIC SET 1
|
||||
| # 38 |
90110-06233 9011006233 9011006233 |
BOLT, HEXAGON SOCKET HEAD
|
||||
| # 39 |
90480-12023 9048012023 9048012023 |
GROMMET
|
||||
| # 40 |
90387-06203 9038706203 9038706203 |
COLLAR
|
||||
| # 41 |
90183-05074 9018305074 9018305074 |
NUT, SPRING(3YX)
|
||||
| # 42 |
14B-2414H-00 14B2414H00 14B2414H00 |
DAMPER, PLATE 1
|
||||
| # 43 |
4C8-24182-00 4C82418200 4C82418200 |
DAMPER, LOCATING 2
|
||||
| # 44 |
3XV-21778-00 3XV2177800 3XV2177800 |
DAMPER, LOCATING 1
|
||||
| # 45 |
14B-24181-00 14B2418100 14B2418100 |
DAMPER, LOCATING 1
|
||||
| # 46 |
90119-05015 9011905015 9011905015 |
BOLT, WITH WASHER
|
||||
| # 47 |
901790552300 901790552300901790552300 |
NUT(1KT)
|
||||
| # 48 |
98902-05014 9890205014 9890205014 |
SCREW, BIND
|
||||
| # 49 |
14B-2414N-20 14B2414N20 14B2414N20 |
DAMPER, PLATE 4
|
||||
| # 50 |
14B-2414P-20 14B2414P20 14B2414P20 |
DAMPER, PLATE 5
|
||||
| # 51 |
5PW-2411J-01 5PW2411J01 5PW2411J01 |
DAMPER, SIDE COVER
|
||||
| # 52 |
5PW-2411J-01 5PW2411J01 5PW2411J01 |
DAMPER, SIDE COVER
|
||||
| # 53 |
5VU-21747-00 5VU2174700 5VU2174700 |
DAMPER
|
||||
| # 54 |
14B-2414K-10 14B2414K10 14B2414K10 |
DAMPER, PLATE 3
|
||||
| # 55 |
14B-2414G-00 14B2414G00 14B2414G00 |
SEAL
|
||||
| # 56 |
90520-08002 9052008002 9052008002 |
DAMPER, PLATE
|
||||
| # 57 |
4C8-21568-01 4C82156801 4C82156801 |
LABEL, WARNING
|
||||
| # 58 |
14B-24106-10 14B2410610 14B2410610 |
TANK SIDE COVER ASSY 1
|
||||
| # 59 |
2C0-2414H-00 2C02414H00 2C02414H00 |
DAMPER, PLATE 1
|
||||
| # 60 |
14B-2414J-00 14B2414J00 14B2414J00 |
DAMPER, PLATE 2
|
||||
| # 61 |
2C0-2414J-00 2C02414J00 2C02414J00 |
DAMPER, PLATE 2
|
||||
| # 62 |
90338-06018 9033806018 9033806018 |
PLUG (434)
|
||||
| # 63 |
90560-05N33 9056005N33 9056005N33 |
SPACER(7YL)
|
||||
| # 64 |
90520-10005 9052010005 9052010005 |
DAMPER, PLATE
|
||||
| # 65 |
98902-05008 9890205008 9890205008 |
SCREW, BIND
|
||||
| # 66 |
14B-24108-10 14B2410810 14B2410810 |
TANK SIDE COVER ASSY 2
|
||||
| # 67 |
2C0-2414H-00 2C02414H00 2C02414H00 |
DAMPER, PLATE 1
|
||||
| # 68 |
14B-2414J-00 14B2414J00 14B2414J00 |
DAMPER, PLATE 2
|
||||
| # 69 |
2C0-2414J-00 2C02414J00 2C02414J00 |
DAMPER, PLATE 2
|
||||
| # 70 |
90338-06018 9033806018 9033806018 |
PLUG (434)
|
||||
| # 71 |
90560-05N33 9056005N33 9056005N33 |
SPACER(7YL)
|
||||
| # 72 |
90520-10005 9052010005 9052010005 |
DAMPER, PLATE
|
||||
| # 73 |
98902-05008 9890205008 9890205008 |
SCREW, BIND
|
Yamaha YZF-R1
Cilinderinhoud: 1000 Jaar: 2012 Model code 1KB8 Kleur: DEEP PURPLISH BLUE METALLIC C
