Winkelwagen
| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
2D1-16382-00 2D11638200 2D11638200 |
AXLE, PUSH LEVER
|
||||
| # 2 |
92907-08600 9290708600 9290708600 |
WASHER(6TA)
|
||||
| # 3 |
99001-07600 9908007600009900107600 |
CIRCLIP(6L2)
|
||||
| # 4 |
93317-11096 9331711096 9331711096 |
BEARING
|
||||
| # 5 |
93102-15212 9310215212 9310215212 |
OIL SEAL (3X3)
|
||||
| # 6 |
93315-21570 9331521570 9331521570 |
BEARING
|
||||
| # 7 |
4C8-16150-00 4C81615000 4C81615000 |
PRIMARY DRIVEN GEAR COMP.
|
||||
| # 8 |
4C8-16154-00 4C81615400 4C81615400 |
PLATE, THRUST 1
|
||||
| # 9 |
90208-25002 9020825002 9020825002 |
WASHER, CONICAL SPRING
|
||||
| # 10 |
4C8-16360-00 4C81636000 4C81636000 |
PRESSURE PLATE ASSY 2
|
||||
| # 11 |
4C8-16370-00 4C81637011004C81637000 |
CLUTCH BOSS ASSY
|
||||
| # 12 |
5VY-16384-00 5VY1638400 5VY1638400 |
PLATE, SEAT
|
||||
| # 13 |
4B1-16383-00 4B11638300 4B11638300 |
SPRING, CLUTCH BOSS
|
||||
| # 14 |
5VY-16331-00 5VY1633100 5VY1633100 |
PLATE, FRICTION 2
|
||||
| # 15 |
5VY-16321-00 5VY1632100 5VY1632100 |
PLATE, FRICTION
|
||||
| # 16 |
5VY-16325-00 5VY1632510005VY1632500 |
DISQUE 2, EMBRAYAGE
|
||||
| # 17 |
5VY-16330-00 5VY1633000 5VY1633000 |
PLATE, FRICTION 2
|
||||
| # 18 |
4C8-16351-00 4C81635100 4C81635100 |
PLATE, PRESSURE 1
|
||||
| # 19 |
93306-00304 9330600315009330600304 |
BEARING(2JN)
|
||||
| # 20 |
90501-240A0 90501240A20090501240A0 |
SPRING, COMPRESSION
|
||||
| # 21 |
90159-06026 9015906026 9015906026 |
SCREW, WITH WASHER
|
||||
| # 22 |
4B1-16384-00 4B11638400 4B11638400 |
PLATE, SEAT
|
||||
| # 23 |
2C0-16539-00 13S1653900002C01653900 |
SPRING
|
||||
| # 24 |
4B1-16325-00 4B11632500 4B11632500 |
PLATE, CLUTCH 2
|
||||
| # 24 |
5VY-16325-00 5VY1632510005VY1632500 |
DISQUE 2, EMBRAYAGE
|
||||
| # 25 |
4B1-16324-00 BR91632400004B11632400 |
PLATE, CLUTCH 1
|
||||
| # 25 |
4B1-16325-00 4B11632500 4B11632500 |
PLATE, CLUTCH 2
|
||||
| # 25 |
5VY-16325-00 5VY1632510005VY1632500 |
DISQUE 2, EMBRAYAGE
|
||||
| # 26 |
4C8-16377-00 4C81637700 4C81637700 |
NUT, LOCK
|
||||
| # 27 |
93310-232R9 93310232R9 93310232R9 |
BEARING
|
||||
| # 28 |
4XV-16356-01 4XV1635601 4XV1635601 |
ROD, PUSH 1
|
||||
| # 29 |
4C8-16340-00 4C81634000 4C81634000 |
PUSH LEVER ASSY
|
||||
| # 30 |
90508-16041 9050816041 9050816041 |
SPRING, TORSION
|
||||
| # 31 |
90201-10029 9020110029 9020110029 |
WASHER, PLATE
|
||||
| # 32 |
99009-10400 9900910400 9900910400 |
CIRCLIP(10W)
|
||||
| # 33 |
5VY-16164-00 5VY1616400 5VY1616400 |
PLATE, THRUST 2
|
||||
| # 34 |
5VY-16181-00 5VY1618100 5VY1618100 |
SPACER 1
|
||||
| # 35 |
5VY-13354-00 5VY1335400 5VY1335400 |
SPROCKET, DRIVE
|
Yamaha YZF-R1 R1
Cilinderinhoud: 1000 Jaar: 2007 Model code 4C82 Kleur: DEEP PURPLISH BLUE METALLIC C
